Structure containing all parameters for keyboard use case. More...
#include <nbgl_use_case.h>
Public Attributes | ||
| nbgl_layoutKeyboardContentType_t | type | |
| type of content | ||
| const char * | title | |
| centered title explaining the screen | ||
| char * | entryBuffer | |
| already entered text | ||
| uint8_t | entryMaxLen | |
| maximum length of text that can be entered | ||
| keyboardMode_t | mode | |
| keyboard mode to start with | ||
| bool | lettersOnly | |
| if true, only display letter keys and Backspace | ||
| bool | numbered | |
| if set to true, the text is preceded on the left by 'number.' | ||
| uint8_t | number | |
| if numbered is true, number used to build 'number.' text | ||
| keyboardCase_t | casing | |
| keyboard casing mode (lower, upper once or upper locked) | ||
| union { | ||
| nbgl_kbdSuggestParams_t suggestionParams | ||
| nbgl_kbdButtonParams_t confirmationParams | ||
| used if type is KEYBOARD_WITH_SUGGESTIONS More... | ||
| }; | ||
Detailed Description
Structure containing all parameters for keyboard use case.
This structure is used to configure the keyboard modal page, including the title, input buffer, keyboard mode, and the type of content (with button or suggestions).
Definition at line 364 of file nbgl_use_case.h.
Member Data Documentation
◆ [union]
| union { ... } nbgl_keyboardParams_t |
◆ casing
| keyboardCase_t nbgl_keyboardParams_t::casing |
keyboard casing mode (lower, upper once or upper locked)
Definition at line 374 of file nbgl_use_case.h.
◆ confirmationParams
| nbgl_kbdButtonParams_t nbgl_keyboardParams_t::confirmationParams |
used if type is KEYBOARD_WITH_SUGGESTIONS
Definition at line 379 of file nbgl_use_case.h.
◆ entryBuffer
| char* nbgl_keyboardParams_t::entryBuffer |
already entered text
Definition at line 367 of file nbgl_use_case.h.
◆ entryMaxLen
| uint8_t nbgl_keyboardParams_t::entryMaxLen |
maximum length of text that can be entered
Definition at line 368 of file nbgl_use_case.h.
◆ lettersOnly
| bool nbgl_keyboardParams_t::lettersOnly |
if true, only display letter keys and Backspace
Definition at line 370 of file nbgl_use_case.h.
◆ mode
| keyboardMode_t nbgl_keyboardParams_t::mode |
keyboard mode to start with
Definition at line 369 of file nbgl_use_case.h.
◆ number
| uint8_t nbgl_keyboardParams_t::number |
if numbered is true, number used to build 'number.' text
Definition at line 373 of file nbgl_use_case.h.
◆ numbered
| bool nbgl_keyboardParams_t::numbered |
if set to true, the text is preceded on the left by 'number.'
Definition at line 372 of file nbgl_use_case.h.
◆ suggestionParams
| nbgl_kbdSuggestParams_t nbgl_keyboardParams_t::suggestionParams |
Definition at line 378 of file nbgl_use_case.h.
◆ title
| const char* nbgl_keyboardParams_t::title |
centered title explaining the screen
Definition at line 366 of file nbgl_use_case.h.
◆ type
| nbgl_layoutKeyboardContentType_t nbgl_keyboardParams_t::type |
type of content
Definition at line 365 of file nbgl_use_case.h.
The documentation for this struct was generated from the following file:
- lib_nbgl/include/nbgl_use_case.h
